D-100 Dual Network Interface Installation Guide 03/18 - 1015-2 / 35094 Page 16
SECTION 2.0: BACnet PICS AND OBJECTS
2.1 PIC STATEMENTS
Network Interface Module BACnet/IP Driver
Conformance Statement (PICS)
Protocol
Date: January 1, 2010
Name: ONICON Incorporated
Name: D-100-BAC Network Interface Module
Product Model: D-100-BAC/IP
Description:
The D-100 Flow Display with Network Interface is a exible platform designed to provide semi-custom solutions to difcult
interface problems. The standard module includes an internal power supply in a NEMA 13 wall mounted enclosure. A variety of optional interface
modules allows for simultaneous connection to multiple networks from one device or provides network access for non-networked sensors.
BACnet Standardized Device Profile (Annex L):
BACnet Smart Sensor (B-SS)
BACnet Smart Actuator (B-SA)
BACnet Application Specific Controller (B-ASC)
BACnet Interoperability Building Blocks Supported (Annex K):
K.1.2 BIBB – Data Sharing – ReadProperty-B (DS-RP-B)
K.1.8 BIBB – Data Sharing – WriteProperty-B (DS-WP-B)
K.5.2 BIBB – Device Management – Dynamic Device
Binding-B (DM-DDB-B)
Segmentation Capability:
None
Standard Object Types Supported:
Device Object Multi State Input Output
Analog Input
Multi State Output
Analog Output
Multi State Value
Analog Value
Binary Input
Binary Output
Binary Value
For all these properties the following apply:
1. Does not support BACnet CreatObject
2. Does not support BACnet DeleteObject
3. Does not support any optional properties
4. No additional
writeable properties exist
5. No proprietary properties exist
6. No range restrictions exist
Data Link Layer Options:
BACnet IP (Annex J)
Networking Options:
BACnet/IP Broadcast Management Device (BBMD)
Does the BBMD support registrations by Foreign
Devices?
Yes
Device Address Binding:
Not supported
Character Sets Supported:
ANSI X3.4.
