2.2 BAC OBJECTS
The table below contains information for each BACnet object. The D-100 operates in
one of two operating modes, unidirectional or bidirectional ow. Please note that for
unidirectional ow applications, Mode 2 objects are not used.
BACNET OBJECT OBJECT DESCRIPTION UNITS NOTES
Analog Input 1 Not Used
Analog Input 2 Volume or Mass Rate GPM, GPH, MGD, L/S,
L/M, L/Hr,
M³/Hr, Lb/Hr, Kg/Hr,
CFS, CFM, No Units
Analog Input 3 Generic Analog Input PSI, BAR, KPA, GPM,
L/S, M³/Hr, CFS, CFM,
KBtu/Hr, KW, TONS,
%RH, Deg F, Deg C, No
Units
Analog Input 4 Generic Analog Input PSI, BAR, KPA, GPM,
L/S, M³/Hr, CFS, CFM,
KBtu/Hr, KW, TONS,
%RH, Deg F, Deg C, No
Units
Analog Value 1 Not Used
Analog Value 2 Mode 1 Volume or Mass
Total
Gallons, Liters, M³, Lbs
Mass, Kg Mass, Ft³, No
Units
Analog Value 3 Not Used
Analog Value 4 Mode 2 Volume or Mass
Total
Gallons, Liters, M³, Lbs
Mass, Kg Mass, Ft³, No
Units
Analog Value 5 Auxiliary Input Total None BACnet will not report
engineering units for this
object
Analog Value 6 Operating Mode
(Unidirectional or
Bidirectional)
Not Applicable 1 = Unidirectional
3 = Bidirectional
Analog Value 12 Bidirectional Flow
Indication
Not Applicable 1 = Mode 1 (forward
direction)
2 = Mode 2 (reverse
direction)
Binary Value 11 Not Used Changing this property
from the (0) inactive state
to the (1) active state will
reset the total to zero.
(Must be priority 8 manual
operator).
Binary Value 12 Zero Mode 1 Volume or
Mass Total
Not Applicable
Binary Value 13 Not Used
Binary Value 14 Zero Mode 2 Volume or
Mass Total
Not Applicable
Binary Value 15 Zero Auxiliary Input
Total
Not Applicable
