2.5 ANALOG VALUE(S)
Property Default Value Read-only or Writable
Object Identier Analog value 1 to 13 Read-only
Object Name Various Read-only
Object Type Analog-value Read-only
Present Value REAL Writable
Status Flags (F,F,F,F) Read-only
Event State normal Read-only
Reliability No-fault-detected Read-only
Out-of-Service FALSE Writable
Units Various Read-only
Description Various Writable
Priority Array
{NULL, NULL, NULL, NULL, NULL, NULL,
NULL, NULL, NULL, NULL, NULL, NULL,
NULL, NULL, NULL, NULL}
Read-only
Relinquish Default 0 Read-only
Analog Value Objects
Object Identier Function
Analog value 2 Mode 1 Volume / Mass Total
Analog value 4 Mode 2 Volume / Mass Total
Analog value 5 Aux Input Total
Analog value 6 Operating Mode
Analog value 12 Mode 1 Mode 2 Indication
Analog value 13 BACnet Instance
Analog value 7-11 are used internally only.
Analog value 1 & 2 are not used.
BACnet Engineering Units for Analog Values (Defaults)
Volume / Mass: Gallons, Liters, M³, Lbs Mass, Kg Mass, Ft³, No Units
Auxiliary pulse inputs: No units (counts)
