D-100 Dual Network Interface Installation Guide 03/18 - 1015-2 / 35094 Page 24
Networking Information MODBUS RTU MODBUS TCP
Connection Information RS485, 2-wire half-duplex Base 10T, 10Mbps, RJ 45 Connection
Data format / Parity 8 bits, 1 stop bit / None 8 bits, 1 stop bit / None
Flow Control (handshaking) None None
Device Address Range 1 - 247 1 - 247
IP Address Not required Default address: 192.168.1.24
Termination (selectable) 120 W or none (default none) None
Biasing None None
3.2 MODBUS MEMORY MAP TABLE
Available Engineering Units
Engineering Units Abbreviation
Volume Rate (Flow)
Gallons per minute GPM
Gallons per minute x 10 GPM x 10
Gallons per hour GPH
Million gallons per day MGD
Liters per second L/S
Liters per minute L/M
Liters per hour L/Hr
Cubic meters per hour M³/Hr
Cubic meters per hour x 10 M³/Hr x 10
Cubic Feet per second Ft³/S
Cubic Feet per minute Ft³/M
Mass Rate (Mass Flow) –
Only available with F-2000 Flow Meter
Pounds per hour Lb/Hr
Pounds per hour x 10 Lb/Hr x 10
Kilograms per hour kg/Hr
Kilograms per hour x 10 kg/Hr x 10
Temperature
Degrees Fahrenheit °F
Degrees Celsius °C
Generic None
Engineering Units Abbreviation
Volume Total
Gallons x 1,000 kGal
Gallons x 1,000,000 MGal
Gallons x 1,000,000,000 GGal
Liters x 1,000 kLiters
Liters x 1,000,000 MLiters
Liters x 1,000,000,000 GLiters
Cubic Meters M³
Cubic Meters x 1,000 kM³
Cubic Feet Ft³
Mass Total -
Only available with F-2000 Flow Meter
Pounds x 1,000 kLbs
Pounds x 1,000,000 MLbs
Kilograms x 1,000 Kkg
Kilograms x 1,000,000 Mkg
