Onkyo CR-N765 User Manual

16
Playing CDs
Selecting tracks on music CDs (Direct Play)
During playback or when stopped, you can use the
remote control number buttons to select a track by
number.
Example: entering track number 7
Press [7].
Example: entering track number 23
Press [>10], [2] and [3].
Playback starts after the track number is input.
Selecting tracks on MP3/WMA discs
This manual refer to MP3, WMA, and other music data as
“file” and a container in which files are stored as “folder”.
When you select a file on a MP3/WMA disc containing
multiple folders, it is convenient to use Navigation mode
or All folder mode.
Navigation mode
In this mode, select the file you want to play by navigating
through the folder hierarchy from the top to lower levels.
For example, in the figure below, folders appear in the
order of 1 to 3, and you can proceed to a deeper level
when you select a folder.
1. When stopped, press the stop (∫) button.
“Root” appears on the display and navigation mode is
activated.
2. Press the playback (1) button.
The name of the first folder inside the “Root” directory
appears.
If there are no folders, the name of the first file
appears.
3. Use the skip (:/9) buttons to select a folder, and
press the ENTER button or playback (1) button to
enter that folder.
0 To select a folder in a folder, repeat this step.
4. Use the skip (:/9) buttons to select a file.
0 To move up one level, press the pause (;) button.
0 To deactivate this mode, press the stop (∫) button.
5. After selecting the desired file, press the ENTER
button or playback (1) button.
Playback starts.
All folder mode
In this mode, only the folders containing music files
appear when you select a file. For example, in the figure
below, folders appear in the order of 1 to 4.
1. When stopped, press the pause (;) button.
“1” appears on the display and all folder mode is
activated.
2. Use the skip (:/9) buttons to select a folder, and
press the ENTER button or playback (1) button to
enter that folder.
3. Use the skip (:/9) buttons to select a file.
0 To return to the folder selection, press the pause
(;) button.
0 To deactivate this mode, press the stop (∫) button.
4. After selecting the desired file, press the ENTER
button or playback (1) button.
Playback starts.
Selecting tracks
[Root]
1
2
3
Same level
*
*
[Root]
1
2
3
4
* Folders with no files in the level directly
below do not appear.
CR-N765_eng.book 16 ページ ２０１４年８月２９日 金曜日 午後２時１８分

Onkyo CR-N765 Specifications

General

Impedance	16 Ω
Receiver type	stereo
Output impedance	470 Ω
Input sensitivity	150 mV
4Ω speaker support	Yes
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (20-20KHz@8 Ohm)	22 W
HDMI in	0
Audio (L/R) in	2
Digital audio optical in	1
Connectivity technology	Wired
Speakers connectivity type	RCA
Audio formats supported	AAC, ALAC, FLAC, LPCM, MP3, WAV, WMA
Bluetooth version	3.0+HS
Bluetooth profiles	APT-X
RDS features	PS, RT
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Optical drive included	No
Display	-
Product color	Silver
Damping factor	58
Package weight	7 kg
Volume control	Rotary
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connector contacts plating	Gold
Package depth	309 mm
Package width	487 mm
Package height	232 mm
7000 g	Weight of the packaged product in gram.
Certification	CE, EAC, EMC
AC input voltage	220-230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	75 W

Weight and Dimensions

Depth	331 mm
Width	215 mm
Height	119 mm
Weight	5000 g
