23
Listening to AM/FM radio
Tuning into stations automatically
1. Press the TUNER button repeatedly to select either
“AM” or “FM” on the display.
2. Press the ENTER button repeatedly until “AUTO”
appears on the display.
3. Press 2 TUN/TUN 1 buttons to start Auto tuning.
0 Searching automatically stops when a station is
found. When tuned into a radio station, the
indicator on the display lights.
When the reception of FM broadcasts is poor: If the
radio wave reception is weak or there is excess noise in
your location, refer to “Tuning into stations manually on
the next page to change the reception setting to
monaural. This can minimise the noise and audio
interruptions.
Tuning into stations manually
If you tune into an FM radio station manually, it will be
received in monaural sound.
1. Press the TUNER button repeatedly to select either
“AM” or “FM” on the display.
2. Press the ENTER button repeatedly until “AUTO” on
the display disappears.
3. Press 2 TUN/TUN 1 buttons to select the desired
radio station.
0 The frequency changes by 1 step each time you
press the button. The frequency changes
continuously if the button is held down and stops
when the button is released. Tune by looking at the
display.
0 You can change the AM frequency step. See “AM
Freq. Step” under “Menu settings” under “Various
settings”.
Tuning into stations by frequency
It allows you to directly enter the frequency of the radio
station you want to listen to.
1. Press the TUNER button repeatedly to select either
“AM” or “FM” on the display.
2. Press D.TUN button.
3. Using the number buttons, enter the frequency of the
radio station within 8 seconds.
0 To enter 87.50 (FM), for example, press [8], [7], [5],
[0]. If the entered number is incorrect, press the
D.TUN button again 8 seconds or more later and re-
enter the number.
Tuning into a radio station
FrequencyBand
CR-N765_eng.book 23 ージ 2014年8月29日 金曜日 午後2時18

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Onkyo CR-N765 and is the answer not in the manual?

Onkyo CR-N765 Specifications

General IconGeneral
Impedance16 Ω
Receiver typestereo
Output impedance470 Ω
Input sensitivity150 mV
4Ω speaker supportYes
Audio output channels2.0 channels
Signal-to-Noise Ratio (SNR)100 dB
Power output per channel (20-20KHz@8 Ohm)22 W
HDMI in0
Audio (L/R) in2
Digital audio optical in1
Connectivity technologyWired
Speakers connectivity typeRCA
Audio formats supportedAAC, ALAC, FLAC, LPCM, MP3, WAV, WMA
Bluetooth version3.0+HS
Bluetooth profilesAPT-X
RDS featuresPS, RT
AM band range522 - 1611 kHz
FM band range87.5 - 108 MHz
Supported radio bandsAM, FM
Preset stations quantity40
Optical drive includedNo
Display-
Product colorSilver
Damping factor58
Package weight7 kg
Volume controlRotary
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connector contacts platingGold
Package depth309 mm
Package width487 mm
Package height232 mm
7000 gWeight of the packaged product in gram.
CertificationCE, EAC, EMC
AC input voltage220-230 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.2 W
Power consumption (typical)75 W
Weight and Dimensions IconWeight and Dimensions
Depth331 mm
Width215 mm
Height119 mm
Weight5000 g
