Onkyo TX-8511

Specifications
AMPLIFIER SECTION
Power Output:
USA & Canadian models; 100 Watts per channel, min RMS. at
European models;
ohms, both channels driven from 20 Hz i
20 kHz. with no more than 0.08?F THD.
2 X 100 Watts at 4 ohms, 1 ItHz (DIN)
Asian models; 2 X 130 Watts at 4 ohms, 1 kHz (ELAJ)
Dynamic power output:
USA & Canadian models;
2 X 170 Watts at 2 ohms
Other area models:
2 X 135 Watts at 4 ohms
2 X 140 Watts at 8 ohms
2 X 143 Watts at 2ohms
Total Harmonic Distortion;
2 X 120 Watts at 4 ohms
2 X 75 Watts at 8 ohms
0.08^ at rated power
IM Distortion:
0.08% at 1 watt output
0.08% at rated power
Damping Factor:
0.08% at 1 watt output
60 at 8 ohms
Input Sensitivity and Impedance:
PHONO:
2.5 mV, 50 kohms
Line (CD.TAPE-l. 2. VIDEO-1, 2):
150 mV, 50 kohms
Video (VIDEO-1. 2);
1 Vp-p. 75 ohms
Output Level and Impedance;
Rec out (T.APE-I. 2):
150 mV, 2.2 kohms
. out (VIDEO-2): 150 mV. 2.2 kohms
Video (VIDEO-2. .MONITOR):
Phono Overload:
1 Vp-p. 75 ohms
120 mV RMS. at 1.000 Hz. 0.5% THD.
Frequency Response; 20 to 30.000 Hz. ±1 dB
RIAA Deviation: 20 to 20.000 Hz. =0.8 dB
Tone Control:
BASS: llOdBat 100 Hz
TREBLE: ±10 dB at 10.000 Hz
Signal to Noise Ratio:
PHO.NO;
80 dB (IHF A. 5 mV input)
CD/TAPE: lOOdB(IHFA)
Muting: -50dB
TUNER SECTION
F.M:
Tuning Range;
U.S. and Canadian models: 87.50 to 108.00 .MHz (100 kHz steps)
European and worldwide models:
Usable Sensitivity;
87.50 to 108.00 .MHz (50 kHz steps)
Mono; 11.2 dBf. 1.0 pV (75 ohms IHF)
50dB Quieting Sensitivity;
0.9pV' (75 ohms DIN)
Stereo: 17.2 dBf. 2.0 uV (73 ohms IHF)
23 pV (75 ohm DIN)
.Mono: 17.2 dBf. 2.0 pV (75 ohms)
Capture Ratio:
Stereo: 37.2 dBf. 20.0 pV (75 ohms)
1.5 dB
Image Rejection Ratio:
U.S. and Canadian models: ■ 40 dB
Other models;
85 dB
n- Rejection Ratio; 90 dB
Sianal-to-Noise Ratio: Mono: 76 dB. IHF
Stereo: 70dB. IHF
.Alternate Channel .Att. (± 4(X) kHz);
Selectivity;
Mono 55 dB. IHF
55 dB DIN (±300 kHz 40 kHz Devi.)
AM Suppre.ssion Ratio: 50 dB
Total Harmonic Distortion: Mono: 0.15%
Frequency Response:
Stereo: 0.25%
30 to 15,000 Hz±l.5dB
Stereo Separation; 45 dB at 1.000 Hz
Stereo Threshold:
30 dB at 100 to 10.000 Hz
17.2 dBf. 2.0 pV (75 ohms)
.AM:
Tuning Range:
U.S- and Canadian models:
530 to 1,710 kHz (10 kHz steps)
European models: 522 to 1.611 kHz (9 kHz steps)
Worldwide models:
530 to 1.710 kHz (10 kHz steps)
Usable Sensitivity;
531 to 1.602 kHz (9 kHz steps)
30 pV
Image Rejection Ratio;
40 dB
IF Rejection Ratio:
40 dB
Signal-to-Noise Ratio;
40 dB
Total Harmonic Distortion: 0.7%
GE.\ER.AL
Power Supply:
U.S. and Canadian models: .ACI20V.60HZ
European and Australian models;
Worldw'ide models;
.AC230 V. 50 Hz
AC 220-230/120 V switchable, 50/60
Power Consumption:
U.S. and Canadian models: 2.8 A
Other models:
220 W
Dimensions (W x H x D); 435 X 150 X 322 mm
Weight:
I7.|/8"x 5-7/8” X 12-11/16"
8.9 kg. 19.6 lbs
REMOTE CONTROL RC-32<)S
Transmitter: Infrared
Signal range:
Approx. 5 meters. 16 ft.
Power supply;
Two "AA" batteries (1.5 V x 2)
Specifications and features are subject to change without notice.
