Setting Item Default Value Setting Details
Height 2 Speaker Top Rear Set the speaker type if height speakers are
connected to the HEIGHT 2 terminals. Select
"Front High", "Top Front", "Top Middle", "Top
Rear", "Rear High", "Dolby Speaker (Front)",
"Dolby Speaker (Surr)" or "Dolby Speaker (Back)"
according to the type and layout of the connected
speakers. However, the options selectable for the
"Height 1 Speaker" the are as follows.
If "Height 1 Speaker" is set to "Front High": Select
from "Top Middle", "Top Rear", "Rear High", "Dolby
Speaker (Surr)" or "Dolby Speaker (Back)".
If "Height 1 Speaker" is set to "Top Front" or "Dolby
Speaker (Front)": Select from "Top Rear", "Rear
High", "Dolby Speaker (Surr)" or "Dolby Speaker
(Back)".
If "Height 1 Speaker" is set to "Top Middle": Fixed
to "Rear High".
•
"Dolby Speaker (Surr)" and "Dolby Speaker
(Back)" can only be selected when surround
speakers or surround back speakers are being
used, respectively. You can check speakers that
you are using on the gure displayed in "Speaker
Channels".
• If an item cannot be selected even though
connection is correct, check that the settings
in "Speaker Channels" matches the number of
connected channels.
Setting Item Default Value Setting Details
Zone Speaker No Set whether speakers are connected to Zone 2 or
Zone 3 speaker terminals.
"Zone 2": When speakers are connected to Zone 2
speaker terminals
"Zone 2/Zone 3": When connecting speaker to both
ZONE 2 speaker terminal and ZONE 3 speaker
terminals.
•
This setting cannot be selected under any of
following conditions.
– When surround back speakers and height
speakers are being used at the same time.
– When 2 sets of height speakers are used
"No": When speakers are not connected to zone 2
or zone 3 speaker terminals
• This setting cannot be selected when "Zone 2
Preout" is set to "Zone B".
Zone 2 Preout Zone 2 Set an output destination of the audio output from
ZONE 2 PRE/LINE OUT or ZONE B LINE OUT
jack.
"Zone 2": When connecting a pre-main amplier in
a separate room (ZONE 2)
"Zone B": When connecting a pre-main amplier,
transmitter of wireless headphones, etc. to ZONE B
• This setting is xed to "Zone 2" when "Zone
Speaker" is set to "Zone 2" or "Zone 2/Zone 3".
Bi-Amp No Set whether the front speakers are bi-amp
connected.
"No": When front speakers are not bi-amp
connected
"Yes": When front speakers are bi-amp connected
• This setting will be set to "No" in either of
following cases.
– When using surround back speakers and two
sets of height speakers at the same time
– When "Zone Speaker" is set to "Zone 2/Zone
3"
– When height speakers and ZONE speakers
are being used at the same time.
