To Non-ARC TV
If the TV does not support the ARC (Audio Return Channel) function (*), connect
an HDMI cable and digital optical cable. If the TV does not have a DIGITAL
OPTICAL OUT jack, you can use an analog audio cable to connect with the
AUDIO IN TV jack.
• If you use a cable set-top box, etc. connected to the input jack of this unit to
watch TV (without using a TV's built-in tuner), connection with a digital optical
cable or analog audio cable is not required.
• Another TV or projector can be connected to the HDMI OUT SUB jack. Switch
between MAIN and SUB using the HDMI MAIN/SUB button on the remote
controller ( p15) or "Quick Menu" ( p180). Note that this jack is not
ARC-compatible.
• If devices with different resolutions are connected to HDMI OUT MAIN jack
and SUB jack, images are output with the lower resolution.
• If a 4K high-quality video is played, use a Premium High Speed HDMI Cable
or Premium High Speed HDMI Cable with Ethernet whose package has
a "PREMIUM Certied Cable" label. Furthermore, press on the remote
controller, and set "1.Input/Output Assign" - "TV Out/OSD" - "HDMI 4K Signal
Format" ( p154) to "Enhanced".
(*) ARC function: Transmits the audio signals of the TV via an HDMI cable, and
plays the audio of the TV on this unit. Connection to an ARC-compatible TV is
complete with one HDMI cable. To check if the TV supports the ARC function,
refer to the instruction manual of the TV, etc.
AC INLET
ETHERNETUSB
6
T V
)
PHONO
FRONT CENTER
2
(
CD
)
3
(
TV
)
1
(
GAME
)
1 2
BACK HEIGHT
OPTICALCOAXIAL
DIGITAL IN
LL
RR
GND
1
SUB
ZONE
2
MAIN
e ARC
ARC
HDMI OUT
4
K HDR
5 V / 1 A
(
ASSIGNABLE
)
1 2
(
BD/ DVD
) (
CBL / SAT
)
~
6
ASSIGNABL
E
)
2
SUB
-
WOOFER
SURROUND
PRE OUT
ASSIGNABL
E
)
SURROUND BACKSURROUND BACK
RR LL RR LL
SURROUNDSURROUND
HEIGHT 1 HEIGHT 1
HEI
GHT 2
HEI
GHT 2
RR
LL RR LL
(
ZONE 3
) (
Bi
-
AMP
)
(
ZON
E 2
)
a
b
TV
a HDMI cable, b Digital optical cable
