Speaker combinations
• Up to two powered subwoofers can be connected in either combination.
Speaker
Channels
FRONT CENTER SURROUND
SURROUND
BACK
HEIGHT 1 HEIGHT 2 Bi-AMP (*1)
ZONE 2 (*1)
(ZONE SPEAKER)
ZONE 3 (*1)
(ZONE SPEAKER)
2.1 ch
3.1 ch
4.1 ch
5.1 ch
6.1 ch
(*2)
7.1 ch
(*2)
2.1.2 ch
(*3) (*4)
3.1.2 ch
(*3) (*4)
4.1.2 ch
(*3) (*4)
5.1.2 ch
(*3) (*4)
6.1.2 ch
(*3)
7.1.2 ch
(*3)
4.1.4 ch
(*5) (*6)
5.1.4 ch
(*5) (*6)
6.1.4 ch
7.1.4 ch
(*1) It is not possible to use Bi-AMP and ZONE speakers at the same time. However, with 2.1 ch to 7.1 ch, it is possible to use Bi-AMP and ZONE 2 speakers at the
same time.
(*2) If you have not connected ZONE 3 speakers in another room but have only connected ZONE 2 speakers, connect the ZONE 2 speakers to the HEIGHT 1 jacks.
However, if Bi-Amping connections are used for front speakers, connect the ZONE 2 speakers to the HEIGHT 2 jacks.
(*3) If front speakers are to be Bi-Amping connected, height speakers need to be connected to the HEIGHT 2 jacks.
(*4) ZONE 2 speakers need to be connected to the HEIGHT 1 jacks, ZONE 3 speakers need to be connected to the SURROUND BACK jacks, and height speakers
need to be connected to the HEIGHT 2 jacks.
(*5) If front speakers are to be Bi-Amping connected, height 1 speakers need to be connected to the SURROUND BACK jacks.
(*6) ZONE 2 speakers need to be connected to the HEIGHT 1 jacks, height 1 speakers need to be connected to the SURROUND BACK jacks.
About the HEIGHT 1/HEIGHT 2
When connecting 2 sets of the height speakers, the combination of the height speakers that can be selected is as follows.
– Height 1 Speaker: Top Middle, Height 2 Speaker: Rear High
–
Height 1 Speaker: Front High; Height 2 Speaker: One of Rear High/Top Middle/Top Rear/Dolby Enabled Speaker (Surround)/Dolby Enabled Speaker (Surround Back)
– Height 1 Speaker: Top Front or Dolby Enabled Speaker (Front), Height 2 Speaker: One of Rear High/Top Rear/Dolby Enabled Speaker (Surround)/Dolby Enabled
