General Specications
Amplier Section
Rated Output Power (FTC) (North American)
With 8 ohm loads, both channels driven, 1 kHz; rated 140 watts per channel
minimum RMS power, with no more than 0.08% total harmonic distortion
from 250 milliwatts to rated output.
Rated Output Power (IEC) (European)
11 ch × 215 W at 6 ohms, 1 kHz, 1 ch driven of 1% THD
Maximum Effective Output Power (JEITA) (North American)
260 W at 6 ohms, 1 kHz, 1 ch driven of 10% THD
Maximum Effective Output Power (JEITA) (European)
260 W at 6 ohms, 1 kHz, 1 ch driven of 10% THD
Multi channel simultaneous power output (1 kHz, 1%, 8 Ω)
880W (11ch Total)
THD+N (Total Harmonic Distortion+Noise)
0.05% (1 kHz, 100W)
Input Sensitivity and Impedance
200 mV/82 kΩ (LINE (RCA))
3.5 mV/47 kΩ (PHONO MM)
Rated RCA Output Level and Impedance
1 V/470 Ω (PRE OUT)
1 V/470 Ω (SUBWOOFER PRE OUT)
200 mV/1.2 kΩ (ZONE B /ZONE 2 /ZONE 3 LINE OUT)
2 V/1.2 kΩ (ZONE 2 /ZONE 3 PRE OUT)
Phono Maximum Input Signal Voltage
70 mV (MM 1 kHz 0.5%)
Tone Control Characteristics (MAIN)
±10 dB, 20 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Tone Control Characteristics (ZONE 2)
±10 dB, 100 Hz (BASS)
±10 dB, 10 kHz (TREBLE)
Signal to Noise Ratio
108 dB (IHF-A, LINE IN, SP OUT)
90 dB (IHF-A, PHONO IN, SP OUT)
Speaker Impedance
4 Ω - 16 Ω
Headphone Rated Output
57 mW + 57 mW (32 Ω, 1 kHz, 10% THD)
Video Section
Signal level
1 Vp-p/75 Ω (Composite Video)
1 Vp-p/75 Ω (Component Video Y)
0.7 Vp-p/75 Ω (Component Video Pb/Pr)
Maximum resolution supported by component video
480i/576i
Tuner Section
FM Tuning Frequency Range
87.5 MHz - 107.9 MHz (North American)
87.5 MHz - 108.0 MHz, RDS (Others)
50 dB quieting sensitivity (FM MONO)
1.0 μV, 11.2 dBf (IHF, 75 Ω)
AM Tuning Frequency Range
530 kHz - 1710 kHz (North American)
522/530 kHz - 1611/1710 kHz (Others)
Preset Channel
40
Network Section
Ethernet LAN
10BASE-T/100BASE-TX
Wireless LAN
IEEE 802.11 a/b/g/n/ac standard
(Wi-Fi
®
standard)
5 GHz/2.4 GHz band
