Onkyo TX SR308

TX-SR308
<Note>
Parts marked by "NSP" are generally unavailable because <Notes>
they are not in our Master Spare Parts List. (B) : Black model
(S) : Silver model
(G) : Golden model
<MDC> : 120V,Canadian model
<MDD> : 120V,USA model
<MDF> : 120V,Taiwanese model
<MMO> : 220/230-240V,Saidi Arabian model
<MMQ> : 220/230-240V,Hong kong model
<MPA> : 230V,Australian model
<MPP> : 230V,CE(European) country model
<MMR> : 220/230-240V,Chinese model
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[TRANS COIL]
T901 P TRANS ( ! ) NPT-1589D 1 2301970 N <MDC, MDD, MDF>
T901 P TRANS ( ! ) NPT-1589P 1 2301971 N <MPA, MPP>
T901 P TRANS ( ! ) NPT-1589M 1 2301972 N
<MMO, MMQ，MMR>
[SEMI CONDUCTOR]
Q6001 IC STK-443-530-E 1 222148
Q6002 IC STK-442-530-E 1 222149
[SW TRM]
F6901 FUSE ( ! ) 8A-T/UL-ST2 1 252261GR !
F6902 FUSE ( ! ) 8A-T/UL-ST2 1 252261GR !
F901 FUSE ( ! ) 4A-SE-EAK FUSE 1 252077GR !
<MMR MMO, MMQ, MPA, MPP>
F901 FUSE ( ! ) 8A-UL/T-233 1 252329GR !
<MDC, MDD, MDF>
F901or FUSE ( ! ) 8A-T/UL-ST2 ( 1) 252261GR !
<MDC, MDD, MDF>
F901or FUSE ( ! ) 4A-SE-TL250V ( 1) 252277GR !
<MMR MMO, MMQ, MPA, MPP>
P101 FFC NCFC7-111512 1 2047111512
P6601A P RIVET JB-407A-C (SP-TRM) 4 880052
<MMR MMO, MMQ, MPA, MPP>
P701 FFC NCFC7-312012 1 2047312012
P901 AC CORD ( ! ) AS-BS 1 253198LTK !
<MMQ>
P901 AC CORD ( ! ) AS-CEE-2 1 253306VOL !
<MMO, MPP>
P901or AC CORD ( ! ) AS-CEE-2 ( 1) 253374YUN !
<MMO, MPP>
P901 AC CORD ( ! ) AS-CCC 1 253355VOL !
<MMR>
P901or AC CORD ( ! ) AS-CCC ( 1) 253377LTK !
<MMR>
P901 AC CORD ( ! ) AS-UC-2 1 253368AYUN !
<MDC, MDD>
P901or AC CORD ( ! ) AS-UC-2 ( 1) 253368BLTK !
<MDC, MDD>
P901 AC CORD ( ! ) AS-SAA 1 253388LTK !
<MPA>
P901 AC CORD ( ! ) AS-CNS 1 253429VOL !
<MDF>
P901 AC CORD ( ! ) AS-CEE-2 1 253306VOL ! <MPP>
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
( ! ) ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
