Onkyo TX SR308

P5503A SOCKET NSCT-9P2189 1 25052292
P5504A SOCKET NSCT-7P2187 1 25052290
P701A SOCKET NSCT-31P2124 1 25052227
P751A SOCKET IMSA-9618S-09A 1 25053334R2
P8001A PLUG IMSA-9111B-16 1 25056620
P8002A PLUG IMSA-9111B-24 1 25056625
TX-SR308
PC BOARD PARTS LIS
T
U004
DIS-AS (DISPLAY ASSY)
(U0040/41/42/43/44)
BADIS-0373-1A * 1 1B247573-1A N <MDC, MDD, MDF>
U004
DIS-AS (DISPLAY ASSY)
(U0040/41/42/43/44)
BADIS-0373-1B * 1 1B247573-1B N <MMO, MMQ, MPA, MPP, MMR>
U0040 DIS-AS (DISPLAY) BADIS-0373-1A 1 1B2475373-1A N <MDC, MDD, MDF>
U0040 DIS-AS (DISPLAY) BADIS-0373-1B 1 1B2475373-1B N <MMO, MMQ, MPA, MPP, MMR>
U0041 PWB (STANDBY/LED) BADIS-0374-1A 1 Included in "REF, NO, U004
0
N <MDC, MDD, MDF>
U0041 PWB (STANDBY/LED) BADIS-0374-1B 1 Included in "REF, NO, U004
0
N <MMO, MMQ, MPA, MPP, MMR>
U0042 PWB (VIDEO) BAVD-0375-1A 1 1B2475375-1A N <MDC, MDD, MDF>
U0042 PWB (VIDEO) BAVD-0375-1B 1 1B2475375-1B N <MMO, MMQ, MPA, MPP, MMR>
U0043 PWB (POW-SUPPLY) BAETC-0376-1A 1 1B2475376-1A N <MDC, MDD, MDF>
U0043 PWB (POW-SUPPLY) BAETC-0376-1B 1 1B2475376-1B N <MMO, MMQ, MPA, MPP, MMR>
U0044 PWB (HP-JACK) BAETC-0377-1A 1 1B2475377-1A N <MDC, MDD, MDF>
U0044 PWB (HP-JACK) BAETC-0377-1B 1 1B2475377-1B N <MMO, MMQ, MPA, MPP, MMR>
CIRCUIT. N
O
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[TUNER UNIT]
U7041 REMO SENS KSM-603TE5B 1 24130019
[SEMI CONDUCTOR]
D7002 ZENER D UDZS8.2B 1 224550820R2
D7033 ZENER D UDZS3.9B 1 224550390R2
D7151 LED SLI-343URC-TE7 1 225449T
D7152 LED SLI-343Y8C-TE7 1 225490T N
D9011 DIODE D5SBA20 1 22380130F
D9014 C-DIODE KDS4148U 1 NSP
D9014 or C-DIODE 1SS352 ( 1) NSP
D9014 or C-DIODE MA2J111 ( 1) NSP
D9015 C-DIODE KDS4148U 1 NSP
D9015 or C-DIODE 1SS352 ( 1) NSP
D9015 or C-DIODE MA2J111 ( 1) NSP
D9016 ZENER D UDZS6.2B 1 224550620R2
D9023 C-DIODE KDS4148U 1 NSP
