Onkyo TX SR308

TX-SR308
PC BOARD PARTS LIS
T
U001
A
F-AS (AMPLIFIER ASSY)
(
U0010/11/12/13/14/15
)
BAAF-0341-1A * 1 1B247541-1A N <MDC, MDD, MDF>
U001
A
F-AS (AMPLIFIER ASSY)
(
U0010/11/12/13/14/15
)
BAAF-0341-1B * 1 1B247541-1B N <MPA, MPP>
U001
A
F-AS (AMPLIFIER ASSY)
(
U0010/11/12/13/14/15
)
BAAF-0341-1C * 1 1B247541-1C N <MMO, MMQ MMR>
U0010 AF-AS (AMPLIFIER) BAAF-0341-1A 1 1B2475341-1A N <MDC, MDD, MDF>
U0010 AF-AS (AMPLIFIER) BAAF-0341-1B 1 1B2475341-1B N <MPA, MPP>
U0010 AF-AS (AMPLIFIER) BAAF-0341-1C 1 1B2475341-1C N <MMO, MMQ MMR>
U0011 PWB (FL TUB -VP) BAPS-0342-1A 1 1B2475342-1A N <MDC, MDD, MDF>
U0011 PWB (FL TUB -VP) BAPS-0342-1B 1 1B2475342-1B N <MPA, MPP>
U0011 PWB (FL TUB -VP) BAPS-0342-1C 1 1B2475342-1C N <MMO, MMQ MMR>
U0012 PWB (TEMP-SEN) BAETC-0343-1A 1 1B2475343-1A N <MDC, MDD, MDF>
U0012 PWB (TEMP-SEN) BAETC-0343-1B 1 1B2475343-1B N <MPA, MPP>
U0012 PWB (TEMP-SEN) BAETC-0343-1C 1 1B2475343-1C N <MMO, MMQ MMR>
U0013 PWB BAETC-0344-1A 1 N NSP <MDC, MDD, MDF>
U0013 PWB BAETC-0344-1B 1 N NSP <MPA, MPP>
U0013 PWB BAETC-0344-1C 1 N NSP <MMO, MMQ MMR>
U0014 PWB (TRANS-TRM) BAETC-0345-1A 1 1B2475345-1A N <MDC, MDD, MDF>
U0014 PWB (TRANS-TRM) BAETC-0345-1B 1 1B2475345-1B N <MPA, MPP>
U0014 PWB (TRANS-TRM) BAETC-0345-1C 1 1B2475345-1C N <MMO, MMQ MMR>
U0015 PWB BAETC-0346-1A 1 N NSP <MDC, MDD, MDF>
U0015 PWB BAETC-0346-1B 1 N NSP <MPA, MPP>
U0015 PWB BAETC-0346-1C 1 N NSP <MMO, MMQ MMR>
CIRCUIT. N
O
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D4171 ZENER D MTZJ6.2B 1 224470622T
D4172 ZENER D MTZJ6.2B 1 224470622T
D4173 DIODE 1SS133 1 223163T
D4174 DIODE 1SS133 1 223163T
D4300 DIODE RL1N4003 1 22380260T
D4300 or DIODE GP104003E ( 1) 22380035T
D4301 DIODE RL1N4003 1 22380260T
D4301 or DIODE GP104003E ( 1) 22380035T
D4302 DIODE RL1N4003 1 22380260T
D4302 or DIODE GP104003E ( 1) 22380035T
D4303 DIODE RL1N4003 1 22380260T
