Onkyo TX SR308 Service Manual

L301 EMIFIL BK1608LM182-T 1 230958R1
L302 EMIFIL BK1608LM182-T 1 230958R1
L303 CHOKE COIL LBC2518T4R7M 1 231364M047R2
L304 CHOKE COIL LBC2518T4R7M 1 231364M047R2
L305 CHOKE COIL LBC2518T4R7M 1 231364M047R2
L307 C-CARBON R RN72K1J-000JE 1 435030004R1
L401 CHOKE COIL LBC2518T4R7M 1 231364M047R2
L402 CHOKE COIL LBC2518T4R7M 1 231364M047R2
L500 CORE BLM18PG181SN1D 1 2350005R1
L742 CHOKE COIL BLM21PG221SN1 1 230949R2
L743 CORE BLM18PG181SN1D 1 2350005R1
L744 CORE BLM18PG181SN1D 1 2350005R1
L746 CORE BLM18PG181SN1D 1 2350005R1
L747 CORE BLM18PG181SN1D 1 2350005R1
X101 CRYSTAL HC-49S 4.332MHz 1 3010469T <MMO, MMQ, MPA, MPP, MMR>
X171 CRYSTAL HC-49US24.576MHz 1 3010490T N
X171A CUSHION (BUTYL) 1 28141748
X501 CERA LOCK CSTCR5M00G53-B0 1 3010356R2
[CAPACITOR]
C102 C-CERA C CK725F1E-104Z1 1 NSP
C103 UTSP C CE04W50V-10M(UTSP) 1 397581007T <MMO, MMQ, MPA, MPP, MMR>
C104 UTSP C CE04W50V-10M(UTSP) 1 397581007T <MMO, MMQ, MPA, MPP, MMR>
C105 C-CERA C CK725F1E-104Z1 1 NSP <MMO, MMQ, MPA, MPP, MMR>
C106 C-CERA C CC725CH1H-331J1 1 NSP <MMO, MMQ, MPA, MPP, MMR>
C107 C-CERA C CK725F1E-104Z1 1 NSP <MMO, MMQ, MPA, MPP, MMR>
C108 C-CERA C CC725CH1H-150J1 1 NSP <MMO, MMQ, MPA, MPP, MMR>
C109 C-CERA C CC725CH1H-150J1 1 NSP <MMO, MMQ, MPA, MPP, MMR>
C110 C-CERA C CC725CH1H-331J1 1 NSP <MMO, MMQ, MPA, MPP, MMR>
C111 UTSP C CE04W25V-47M(UTSP) 1 397554707T
C112 C-CERA C CK725F1E-104Z1 1 332161040R1
C113 C-CERA C CC725CH1H-221J1 1 NSP <MMO, MMQ, MPA, MPP, MMR>
C114 UTSP C CE04W25V-47M(UTSP) 1 NSP
C130 C-CERA C CK725F1E-104Z1 1 332161040R1
C131 C-CERA C CC725CH1H-101J1 1 NSP
C133 C-CERA C CK725B1C-104K1 1 NSP
C135 C-CERA C CC725CH1H-080D1 1 NSP
C139 UTSP C CE04W10V-220M(UTSP) 1 NSP
C140 C-CERA C CK725F1E-104Z1 1 332161040R1
C141 C-CERA C CK725F1E-104Z1 1 NSP
C142 C-CERA C CK725F1E-104Z1 1 NSP
C143 C-CERA C CC725CH1H-330J1 1 NSP

Onkyo TX SR308 Specifications

General

Impedance	6 Ω
Frequency range	20 - 50000 Hz
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Radio Data System (RDS)	Yes
Product color	Black
Package depth	537 mm
Package width	416 mm
Package height	268 mm
Dimensions (WxDxH)	435 x 151 x 328 mm
Power requirements	AC 220-230 V, 50/60 Hz
Package weight	10500 g
Power consumption (typical)	310 W

Weight and Dimensions

Weight	8000 g
