Onkyo TX SR308

P6913 WS CLAMP CB-71683(L=50) 1 260261
RL601 RELAY NRL-2P5A-DC12-192 1 25065702
RL602 RELAY NRL-2P5A-DC12-192 1 25065702
RL603 RELAY NRL-2P5A-DC12-192 1 25065702
RL605 RELAY NRL-2P5A-DC12-192 1 25065702
RL691 RELAY NRL-1P10A-DC12-196 1 25065707
RL691 or RELAY NRL-1P10A-DC12-197 ( 1) 25065708
RL691 or RELAY NRL-1P10A-DC12-198 ( 1) 25065709
RL692 RELAY NRL-1P10A-DC12-196 1 25065707
RL692 or RELAY NRL-1P10A-DC12-197 ( 1) 25065708
RL692 or RELAY NRL-1P10A-DC12-198 ( 1) 25065709
[CHASSIS SCREW]
Q4170A HEAT-SINK HEAT-SINK(RAD-68) 1 NSP
Q4170B SCREW 3P+10FN(3BC) 1 NSP
Q4171A HEAT-SINK HEAT-SINK(RAD-68) 1 NSP
Q4171B SCREW 3P+10FN(3BC) 1 NSP
TX-SR308
PC BOARD PARTS LIS
T
U003
DG-AS (MPU/DAC ASSY)
(
U0030/31
)
BADG-0364-1A * 1 1B247564-1A N <MDC, MDD, MDF>
U003
DG-AS (MPU/DAC ASSY)
(
U0030/31
)
BADG-0364-1B * 1 1B247564-1B N <MMO, MMQ, MPA, MPP, MMR>
U0030 DG-AS (MPU/DAC) BADG-0364-1A 1 1B2475364-1A N <MDC, MDD, MDF>
U0030 DG-AS (MPU/DAC) BADG-0364-1B 1 1B2475364-1B N <MMO, MMQ, MPA, MPP, MMR>
U0031 PWB (U-PORT) BAETC-0365-1A 1 1B2475365-1A N <MDC, MDD, MDF>
U0031 PWB (U-PORT) BAETC-0365-1B 1 1B2475365-1B N <MMO, MMQ, MPA, MPP, MMR>
CIRCUIT. N
O
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[TUNER UNIT]
U131 PHT CP JSR1165-001recieving 1 24120143
U132 PHT CP JSR1165-001recieving 1 24120143
[SEMI CONDUCTOR]
D110 C-DIODE KDS4148U 1 NSP
D110 or C-DIODE 1SS352 ( 1) NSP
D110 or C-DIODE MA2J111 ( 1) NSP
D111 C-DIODE KDS4148U 1 NSP
D111 or C-DIODE 1SS352 ( 1) NSP
D111 or C-DIODE MA2J111 ( 1) NSP
D112 ZENER D UDZS10B 1 224551000R2
D131 C-DIODE KDS4148U 1 NSP
