Onkyo TX SR308 - Page 71

S7136 PUSH SW NPS-111-S681 1 25035718T
S7138 PUSH SW NPS-111-S681 1 25035718T
S7140 PUSH SW NPS-111-S681 1 25035718T
S7142 PUSH SW NPS-111-S681 1 25035718T
S7144 PUSH SW NPS-111-S681 1 25035718T
S7146 PUSH SW NPS-111-S681 1 25035718T
S7148 PUSH SW NPS-111-S681 1 25035718T
S7150 PUSH SW NPS-111-S681 1 25035718T
S7152 PUSH SW NPS-111-S681 1 25035718T
S7154 PUSH SW NPS-111-S681 1 25035718T
S7156 PUSH SW NPS-111-S681 1 25035718T
S7158 PUSH SW NPS-111-S681 1 25035718T
S7160 PUSH SW NPS-111-S681 1 25035718T
S7162 PUSH SW NPS-111-S681 1 25035718T
S7164 PUSH SW NPS-111-S681 1 25035718T
TX-SR308
PC BOARD PARTS LIS
T
U007 HDM-AS
(
HDMI ASSY
)
BAHDM-0401-1A * 1 1B247501-1
A
N
CIRCUIT. N
O
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D8100 C-DIODE KDS4148U 1 NSP
D8100 or C-DIODE 1SS352 ( 1) NSP
D8100 or C-DIODE 1SS355 ( 1) NSP
D8100 or C-DIODE MA2J111 ( 1) NSP
D8951 DIODE XBS303V17R 1 22380365R2
D8971 DIODE XBS303V17R 1 22380365R2
Q201 IC D788E001BRFP266Z 1 22242502R3
Q203 IC TC7WU04FU(TE12L_F) 1 22240935R2
Q203 or IC TC7WZU04FU(TE12L_F) ( 1) 22242078R2TO
Q271 IC XC6220B121PR 1 22242626R2 N
Q281 IC K4S641632N-LC60 1 22242603R2
Q281 or IC EM638165TS-7G ( 1) 22242607R2
Q282 IC (DSP, Flash memory) ES29LV160ET-70TG(0372) 1 222W0069R303726
Q282 or IC (DSP, Flash memory) S29AL016J70TFI010(0372) ( 1) 222W0100R303726
Q282 or IC (DSP, Flash memory) ES29LV160FT-70T(0372) ( 1) 222W0101R303726
Q282 or IC (DSP, Flash memory) MX29LV160DTTI-7(0372) ( 1) 222W0104R303726
Q8101 IC ADV7623 1 22242625R3 N
Q8104 IC S-812C50BUC-C5ET2G 1 22242407R2
Q8105 IC (OSD, Flash memory) EN25Q32A-100HIP(0378) 1 222W0112R203785
