8
Part Names
Front Panel
A ON/STANDBY button
B MUSIC OPTIMIZER button: Turns on/o the
Music Optimizer function that improves the
quality of the compressed audio.
C PHONES jack: Connect headphones with a
standard plug (ø1/4″/6.3 mm).
D LISTENING MODE button: Switches the
listening mode ( →p38) by pressing
"STEREO", "MOVIE/TV" and "MUSIC"
repeatedly.
E Input selector buttons: Switches the input to be
played.
F TONE CONTROL button: You can adjust the
sound quality. Press / LEFT/RIGHT for the
“TREBLE”/”VOCAL”/”BASS” item you want to
adjust. ( →p45)
G SETUP MIC jack: Connect the supplied speaker
setup microphone. ( →p76)
H MASTER VOLUME
