Thermocode 2 Printer manual Version 2.04 January 2011 26
26
[F]LABEL1
Speed: <100> (mm/s)
Burn: <200> [50 - 305]
Edit and press ENTER
[F]LABEL1
Rotation:
<0> (0)
Edit and press ENTER
[F]LABEL1
Printhead Pressure
<20> 20-35 Range
Edit and press ENTER
[F]LABEL1
Rotation:
<2> (180)
Edit and press ENTER
STATUS DISPLAY SOFTWARE FLOWCHARTS (Level 3: ENGINEER)
THERMOCODE 53C
1> [S] Print On Line
2 [F] LABEL1
3 Select Format
4Service
5 Information
6 Supervisor
7Contact
8Test Print
9 Passcodes
WARNING
THIS ACTION CANCELS
PRINTING, PROCEED ?
NO YES
[F]LABEL1
1> Print Speed/Burn
2 Pressure
3 Rotation
4 Move X / Y Position
5 Text sizes (Y,X)
[F]LABEL1
1> Offset
2 Set Parameters
3 Edit Fields
4 Set Quantity
5Save As….
6 Crossweb Settings
[F]LABEL1
1> Texts
2 Counters
[F]LABEL1
Move X Pos. < +0.0 > mm
Move Y Pos. < +0.0 > mm
Edit and press ENTER
[F]LABEL1
>LotNumber
Batch
Expiry
[F]LABEL1
Field: LotNumber
< 1234567 >
ENTER = save ( 1 )
CHARGEHAND
Set the Passcode
and press ENTER
< if activated>
ENGINEER
Set the Passcode
and press ENTER
< if activated>
Right Arrow to change
V
[F]LABLE1
> y0077,X0038 - Arial
y0153,X0038 - Arial
y0153,X0125 - Arial
[F]LABLE1
Y:<0077> X:<0038>
Font: Arial
Height: <12> Points
With the system variable NOOVERFLOWMSG
set to 1. You Select a line of text. Then can Edit
the X & Y position also the actual Point size.
Use the up/down arrows to toggle the field to edit.
