STATUS DISPLAY SOFTWARE FLOWCHARTS (Level 4: MANAGER)
Counters: Counter1
Start no. < 12345678 >
Leading Zero’s: < Y >
Press ENTER for NEXT
Counters: Counter1
Increment Amount < 1 >
Increment After < 2 >
Press Enter for NEXT
Counters: LABEL1
>Counter1
Counter2
Counter3
Counters: Counter1
Counter Rollover < Y >
R.Number < 123456 >
Batch Qty < 123456 >
MANAGER
Set the Passcode
and Press ENTER
< if activated>
THERMOCODE 53S
1> [S] Print On Line
2[F] LABEL1
3 Select Format
4 Service
5 Information
6 Supervisor
7Contact
8Test Print
9Passcodes
WARNING
THIS ACTION CANCELS
PRINTING, PROCEED ?
NO YES
[F]LABEL1
1> Print Speed/Burn
2 Pressure
3Rotation
4 Move X / Y Position
[F]LABEL1
1> Offset
2 Set Parameters
3 Edit Fields
4 Set Quantity
5Save As….
6 Crossweb settings
[F]LABEL1
1> Texts
2 Counters
[F]LABEL1
Speed: <100> (mm/s)
Burn: <200> [50 - 305]
Edit and press ENTER
[F]LABEL1
Rotation:
<0> (0)
Edit and press ENTER
[F]LABEL1
Printhead Pressure
<20> 20-35 Range
Edit and press ENTER
[F]LABEL1
Move X Pos. < +0.0 > mm
Move Y Pos. < +0.0 > mm
Edit and press ENTER
[F]LABEL1
>LotNumber
Batch
Expiry
[F]LABEL1
Field: LotNumber
< 1234567 >
ENTER to save ( 1 )
CHARGEHAND
Set the Passcode
and press ENTER
< if activated>
ENGINEER
Set the Passcode
and press ENTER
< if activated>
[F]LABEL1
Rotation:
<2> (180)
Edit and press ENTER
V
Right Arrow to change
