Oppo SonicaDAC - Installation; Front Panel Controls; Back Panel Connectors

4

Installation
FrontPanelControls

1. PowerButton 2. PowerStatusIndicator 3. SourceSelector/FunctionKnob
4. FrontPanelDisplay 5. USBPort(TypeA,Host) 6. VolumeKnob

BackPanelConnectors

1. XLRBalancedAudioOutput 2. RCAStereoAudioOutput 3. CoaxialDigitalAudioInput
4. OpticalDigitalAudioInput 5. USBAudioInput(TypeB) 6. AUXAudioInput(RCA)
7. TriggerInput&Output 8. EthernetPort 9. USBPort(TypeA,Host)
10. GroundConnector 11. VoltageSwitch 12. ACInlet

