Technical data
Version 1.2.4 - 2022-10-2616 Translation of original instruction
S275N | S275NV
EN
S275N_S275NV_GB_2.fm
2 Technical data
The following information represents the dimensions and indications of weight and the
manufacturer‘s approved machine data.
Electrical connection
S275N S275NV
Connection 3 x 400 V; 50 Hz; 1.1 KW 230 V; ~50 Hz; 1.5 KW
Cutting area
S275N S275NV
Possible cutting areas S275N and S275NV on page 31
General
S275N S275NV
Cutting angle adjustment using the rotating saw arch 0° - 60°
Saw belt guide Saw belt guides supported on ball bearings
Raising the saw arch manually
Feed continuously adjustable
Saw band tension Manually using the hand wheel
Dimensions
S275N S275NV
Weight of the metal band saw [kg] 185
Dimensions of saw blade [mm] 2480 x 27 x 0.9
Dimensions S275N │ S275NV on page 20
Speed of saw belt
S275N S275NV
[m/min] 45 | 90 20 - 90
Transmission ratio drive / saw belt pul-
ley [~50 Hz ]
1.30 1:20
Transmission ratio drive / saw belt pul-
ley [~60 Hz ]
01:40 1:20
Coolant pump
S275N S275NV
Power 90 W 90 W
Speed [ min
-1
] 2850 2850
Tank capacity [ liter ] 10 10
Operating material
S275N S275NV
Hydraulic cylinder Hydraulic oil, viscosity 32 - 46 as per DIN 51519, HLP Quality
Helical gear Mobilgear 636, viscosity 680 mm
2
/s (about 0,33 liters)
Spindle of the machine vice Commercial lubricating grease
