4 Operation
4.1 Control and indicating elements
Pos. Designation Pos. Designation
1
Handle
2
Saw band tension
3
Saw arch
4
Adjustable saw belt and coolant hose
guide
5
Quick-action vice
6
Clamping lever
angular adjustment saw arch
7
Control panel
8
Feed regulation valve
9
Sawing stop
3
7
1
2
4
5
6
8
9
