Page 12
DX17VGB
2 Technical specification
The following information represents the dimensions and indications of weight and the manu-
facturer‘s approved machine data for following stated machines.
CAUTION!
The machine operator should use hearing protection.
INFORMATION
This numerical value was measured on a new machine under the operating conditions specified
by the manufacturer. The noise behaviour of the machine might change depending on the age
and wear of the machine. Furthermore, the noise emission also depends on production engi-
neering factors, e.g. speed, material and clamping conditions.
Electrical connection
230 V / 1 Ph 50 Hz~60 Hz
Setting the bas
ic frequency to 60Hz, see the Sinamics operating instructions V20
Drive Motor Output
1 k
W/1.35HP
Drilling capacity
Drilling capacity in steel (S235JR)
Ø 16 mm/0.63"
Continuous drilling capacity in steel
(S235JR)
Ø 13 mm/0.5"
Spindle seat
B16 with Item no. 3020170 or MT2 with Item no. 3020165
Spindle stroke
60 mm/2.36"
Dimensions
"Dimensions“ on page 12
Machine Weight
73 kg / 163 LBS
Spindle speeds
infinitely variable 50 - 4000 min
-1
Emissions
Maximum sound pressure level at 1 m
distance from the machine and 1.60 m
above the ground.
72 dB(A) in idle running
Environmental conditions temperature
Temperature 5 - 35 °C
Relative humidity 25 - 80%
