Page 9
DX17
V GB
Obligations of the operator
obtain training in handling the drilling machine,
know the function and mode of operation,
before taking the machine in operation
- have read and understood the operating manual,
- be familiar with all safety devices and instructions.
Additional requirements apply for work on the following machine components:
Electrical parts or operating agents: shall only be performed by an electrician or under the
guidance and supervision of an electrician.
1.7 Operator positions
The operator’s position is in front of the drilling machine.
1.8 Safety devices
Use the drilling machine only with properly functioning safety devices. Stop the drilling machine
immediately if there is a failure on the safety device or if it is not functioning for any reason. It is
your responsibility!
If a safety device has been activated or has failed, the drilling machine must only be used if you
the cause of the fault has been eliminated,
you have verified that there is no danger to personnel or objects.
1.9 Emergency-stop push button
ATTENTION!
Also after pressing the EMERGENCY-Stop switch, depending on the previously selected
speed, the drilling spindle continues to turn for a few more seconds .
1.10 Main switch
WARNING!
Dangerous voltage even if the main switch is switched off.
The areas marked by the pictogram might contain live parts, even if the main switch is
switched off.
In the "0" position, the main switch can be secured against accidental or non-authorised switch-
ing on. The power supply is interrupted by switching off the main plug.
1.11 Drilling table
Seats for T-slots are attached to the drilling table.
WARNING!
Risk of injury due to workpieces flying off at high speed. Securely fix the workpiece on
the drilling table.
