DX17VGB
4.3.1 Basic Value Setting
To retrieve the basic value settings.
Close the drill chuck protection
Subsequently press the tool selection button and stop .
Then release the buttons again.
INFORMATION
Do not press the buttons simultaneously, press the first button and hold, press the second but-
ton and release both buttons afterwards.
Menu items:
[Clear drill No, press then stop press then stop] - Reset piece counter for drilling
[ Clear tap No, press then stop] - Reset piece counter for drilling screw threads
[ Mass Unit: inch, press stop button] - Use inches as a unit of measure
[ Mass Unit: MM, press stop button ] - Use millimetre as a unit of measure
[ Change language ] - Language selection
Select the menu item with the rotary knob.
Press the button to delete, or to change, and to exit from basic value setting.
4.3.2 Configuring general settings
Inputs can be set using the rotary knob, and confirmed with the Enter key.
The settings are complete if no flashing icon is displayed.
4.3.3 Preset speeds
The control panel includes preset, universal speeds depending on the tool, the tool size and the
material of the workpiece.
The preset speed can be changed with the rotary knob as required after completion of all
entries.
4.3.4 Setting the drilling or thread depth
To adjust the drilling depth.
Close drill chuck protection.
Subsequently press the tool selection button and workpiece offset .
Then release the buttons again.
INFORMATION
Do not press the buttons simultaneously, but one after the other and release them afterwards.
If the symbol blinks, the drilling or thread depth can be adjusted with the rotary knob
and confirmed with the Enter key.
