Version 1.0 dated 2019-01-08Page 40 Translation of the original instructions
B13 basic | B14 basic | B16 basicGB
B13-B14-B16_basic_GB.fm
OPTIMUM
MASCHINEN - GERMANY
®
INFORMATION
Organise the checks according to the following table;
1.11 Emergency stop switch
CAUTION!
The drilling spindle keeps turning for a short time even after actuating the emergency
stop switch depending on the preset speed.
1.11.1 Drilling table
Seats for T-slots are attached to the clamping table.
WARNING!
Risk of injury due to workpieces flying off at high speed. Securely fix the workpiece on
the drilling table.
1.12 Separating protective devices
1.12.1 Drill chuck guard
Adjust the guard to the correct height before you start working. To do this, loosen the clamping
screw, set the required height and tighten the clamping screws again.
1.12.2 Protective cover of the V-belts
A protective cover for the belt pulleys is mounted on the drilling head. There is a switch inte-
grated in the protective cover which monitors that the cover is closed.
INFORMATION
The machine cannot be started, if the protective cover is not closed.
General check
Equipment Check OK
Guards Mounted, firmly bolted and not damaged
Signs,
Markers
Installed and legible
Date: Checked by (signature):
Functional check
Equipment Check OK
Emergency stop switch After actuating the emergency-stop switch the bench
drill must be switched off.
Position switch of protective cover
V-belt
The bench drill must not be switched on, if the protec-
tive cover of the V-belts is opened.
Date: Checked by (signature):
