Version 1.0 dated 2019-01-08Page 44 Translation of the original instructions
B13 basic | B14 basic | B16 basicGB
B13-B14-B16_basic_GB.fm
OPTIMUM
MASCHINEN - GERMANY
®
Furthermore, the noise emission also depends on production engineering factors, e.g. speed,
material and clamping conditions.
INFORMATION
The specified numerical value represents the emission level and does not necessarily a safe
working level. Though there is a dependency between the degree of the noise emission and the
degree of the noise disturbance it is not possible to use it reliably to determine if further precau-
tion measures are required or not. The following factors influence the actual degree of the noise
exposure of the operator:
Characteristics of the working area, e.g. size or damping behaviour,
other noise sources, e.g. the number of machines,
other processes taking place in proximity and the period of time, during which the operator
is exposed to the noise.
Furthermore, it is possible that the admissible exposure level might be different from country to
country due to national regulations. This information about the noise emission should, how-
ever, allow the operator of the machine to more easily evaluate the hazards and risks.
3 Assembly
3.1 Scope of delivery
Check the bench drill immediately after delivery for transport damage, missing parts and loose
locking bolts.
Compare the scope of delivery with the delivery note. Drilling machines in the standard pack-
age will be delivered as indicated below.
The standard delivery are:
3.2 Storage
ATTENTION!
Incorrect and improper storage might result in damage or destruction of electrical and
mechanical machine components.
Store packed and unpacked parts only under the intended environmental conditions.
Follow the instructions and information on the transport box.
Consult Optimum Maschinen Germany GmbH if the machine and accessories are stored for
more than three months or are stored under different environmental conditions than those spec-
ified here .
B13 / B14 B16
• Drill head • Drill head
• Drilling table • Drilling table
•Stand •Stand
• Column component with pre-assembled table
carrier
• Column component with pre-assembled table
carrier
• Drill chuck • Drill chuck taper mandrel MT 2
• Drill drift
• 3 x handle bar for spindle sleeve lever • 3 x handle bar for spindle sleeve lever
• Operating Manual • Operating Manual
