2 Technical specification
2.1 Emissions
CAUTION!
The user must wear noise protection and hearing protection.
The A-weighted sound pressure level L
pA
is 76 to 79 dB.
The A-weighted sound power level L
WA
is 88 to 91 dB.
INFORMATION
This numerical value was measured on a new machine under the operating conditions specified
by the manufacturer. The noise behaviour of the machine might change depending on the age
and wear of the machine.
Electrical connection
B 13 basic B 14 basic B 16 basic
Connection ~50Hz or ~60Hz 230 V; 300 W 230 V, 350W 230 V, 450 W
Drilling capacity
Drilling capacity in steel [mm] 13 14 16
Throat [mm] 104 104 125
Spindle sleeve stroke [mm] 50 50 65
Spindle seat
Spindle seat fixed / B16 fixed / B16 MT2
Drilling table
Table size [mm]
Length x Width of the working surface
160 x 160 160 x 160 200 x 200
T-slot size [mm] 14 14 14
Maximum distance [mm]
spindle - table
240 330 390
Working surface stand [mm]
Length x Width of the working surface
135 x 175 140 x 180 160 x 170
Dimensions
Height [mm] 580 700 820
Depth [mm] 420 420 510
Width [mm] 220 230 270
Total weight [kg] 19 21 36
Column diameter [mm] 46 46 60
Speeds
"Speed tables“ on page 50
Environmental conditions
Temperature 535 °C
Relative humidity 25 - 80 %
Operating material
toothed rod standard plain bearing grease
Drilling column Acid-free lubricating oil
