Safety
Version 2.1.1 - 2020-07-27 13Translation of original instruction
B40 GSP EN
B40GSP_GB_1.fm
1.9.1 EMERGENCY-STOP push button
CAUTION!
Also after actuating the EMERGENCY-
STOP switch, the drilling spindle is
turning - depending on the previously
selected speed - for a few seconds
more.
Img.1-2: EMERGENCY-STOP button
1.9.2 Main switch
The lockable main switch can be secured
in position "0" by a padlock to prevent
unauthorized or accidental activation.
When the main switch is off, the power
supply to the machine is completely inter-
rupted.
Img.1-3: Main switch
Except for the areas marked by the pictogram in the margin. In these areas there might be volt-
age, even if the main switch is switched-off.
1.9.3 Drilling table
Seats for T-slots are attached to the drill-
ing table.
WARNING!
Risk of injury due to parts flying off at
high speed. Securely fix the workpiece
on the drilling table.
Img.1-4: Drilling table
