3.6.2 Assembly drawing
Img.3-3: Assembly drawing
ATTENTION!
Tighten the fixing screws of the geared drill only as much that it is safely fixed and
cannot break away or tilt over.
If the fixing screws are too tight in particular in connection with an uneven substructure it may
result in a broken stand of the machine.
3.7 Cleaning of the machine
CAUTION!
Do not use compressed air to clean the machine.
Your new machine must be completely cleaned after it is unpacked to ensure that all moving
parts and sliding surfaces are not damaged when the machine is operated. Each unit leaves
the factory with all exposed parts and sliding surfaces suitably greased to avoid oxidation dur-
ing the time that elapses before it is placed into operation. Remove all the wrapping and clean
all the surfaces with a degreaser to soften and remove the protecting greases and coatings.
Clean all the surfaces with a clean cotton cloth and lubricate the machine as explained in the
following section, before connecting the power and beginning to operate the machine.
