Technical data
Version 2.1.1 - 2020-07-2718 Translation of original instruction
B40 GSP
EN
B40GSP_GB_2.fm
2 Technical data
The following information gives the dimensions and weight and is the manufacturer‘s authorised
machine data.
2.1 Electrical connection
Total connected load 3 x 400V; 1.5 KW
Coolant pump 400V ~40W
permitted voltage tolerance 380 V - 420 V
Degree of protection IP 54
2.2 Drilling capacity
Drilling capacity in steel [mm] 35
Tapping in steel [mm] M 24
Drilling capacity in cast [mm] 45
Tapping in cast [mm] M 30
Throat [mm] 350
Sleeve travel [mm] 180
2.3 Spindle seat
Spindle seat MT4
Spindle sleeve feed [mm/rev] 2 stages
0.1 and 0.2
2.4 Drilling table
Table measurements [mm] Length x Width of work
area
560 x 560
T-slot size [mm] 18
Maximum distance [mm] spindle - table 780
Work area of foot [mm] Length x Width of work
area
510 x 500
Maximum distance [mm] spindle - foot 1320
max. bearing load [kg] 250
2.5 Working area
Height [mm] 2400
Depth [mm] 1800
Width [mm] 1400
Weight [kg] 500
2.6 Speeds
Spindle speeds [ min
-1
] 50 - 1450 ( at connection ~ 50Hz )
60 - 1740 ( at connection ~ 60Hz )
