Maintenance
Version 2.1.1 - 2020-07-2740 Translation of original instruction
B40 GSP
EN
B40GSP_GB_5.fm
Start of shift
after every
maintenance
or repair work
Drill head
Oil level of the gear of the drilling spindle sleeve
Check the oil level in the inspection glass The glass oil level (
deposed ) should be half-covered.
Abb.6-2: Oil level of the gear of the drilling spindle sleeve
Abb.6-3: Functional schematic
Interval Where? What? How?
Filler hole
Oil flow
during operation
Oil level when oil depos-
ited
Oil drain plug
