Technical data
Version 1.1.5 dated 2015-08-31 Page 17Original operating instructions
BF30Vario GB
2 Technical data
The following information are the dimensions and indications of weight and the manufacturer‘s
approved machine data..
2.1 Electrical connection
Motor 230V / 50Hz / 2.2 kW
2.2 Drilling-milling capacity
Drilling capacity in steel [mm] max. Ø 25
Drilling capacity in cast [mm] max.
Ø 28
Milling capacity end mill [mm] max. Ø 30
Milling capacity milling head [mm] max. Ø 75
Throat [mm] 220
2.3 Spindle seat
Spindle seat MT3 ISO 30
Draw-in rod M12
Spindle sleeve stroke [mm] 90 mm
2.4 Drill-Mill head
Swivelling + / - 45°
Reduction stages 3
Travel of Z axis [mm] 470
2.5 Cross table
Table length [mm] 750
Table width [mm] 210
Travel of Y axis [mm] 200
Travel of X axis [mm] 450
T - slot size / number / distance [mm] 12 / 63
max. load 150kg
2.6 Working area
Height [mm] 2100
Depth [mm] 1900
Width [mm] 2500
2.7 Speeds
Gear stage slow [min
-1
] 80 - 963
Gear stage average [min
-1
] 135 - 1621
Gear stage rapid [min
-1
] 257 - 3100
