Appendix
Version 1.1.5 dated 2015-08-31Page 64 Original operating instructions
BF30VarioGB
8 Appendix
8.1 Copyright
This document is copyright. All derived rights are also reserved, especially those of translation,
re-printing, use of figures, broadcast, reproduction by photo-mechanical or similar means and
recording in data processing systems, neither partial nor total.
Subject to technical changes without notice.
8.2 Terminology/Glossary
8.3 Change information manual
Term Explanation
Cross table Bearing surface, clamping surface for the workpiece with X- and Y-axis travel
Taper mandrel Cone of the drill or of the drill chuck
Workpiece Piece to be milled, drilled or machined.
Draw-in rod Threaded rod to fix the taper mandrel in the spindle sleeve.
Drill chuck Drill bit chuck
Collet chuck Holder for end mill
Drill-Mill head Upper part of the drilling-milling machine
Spindle sleeve Hollow shaft in which the milling spindle turns.
Milling spindle Shaft activated by the motor
Drilling table Supporting surface, clamping surface
Taper mandrel Cone of the drill or of the drill chuck
Spindle sleeve lever Manual operation for the drill feed
Quick action - drill
chuck
Drill chuck can be fixed by hand.
Workpiece Piece to be drilled or machined.
Tool Milling cutter, drill bit, etc.
Chapter Short note new version number
4.3 Warming up of the drilling-milling machine
Fast on and off.
1.1.1
1.3.1 Avoiding misuses 1.1.2
EC declaration changed standard 1.1.3
4.11 New digital display for spindle sleeve travel 1.1.4
2 Speeds 1.1.5
