Page 152 Operating and Programming — Milling
Appendix
Brief instruction 808D Milling
Group 13: Workpiece measuring inch/metric
Name Meaning
G70 Inch dimension data input
G71 * Metric dimension data input
G700 Inch dimension data input; also for feedrate F
G710 Metric dimension data input; also for feedrate F
Group 14: Absolute/incremental dimension modally effective
Name Meaning
G90 * Absolute dimensions data input
G91 Incremental dimension data input
Group 15: Feedrate / Spindle modally effective
Name Meaning
G94 Feedrate mm/min
G95 Feedrate F in mm/spindle revolutions
Group 16: Feedrate override modally effective
Name Meaning
CFC * Feedrate override with circle ON
CFTCP Feedrate override OFF
Group 18: Behavior at corner when working with tool radius compensation
Name Meaning
G450 * Transition circle
G451 Point intersection
Group 44: Path segmentation with SAR modally effective
Name Meaning
G340 * Approach and retraction in space (SAR)
G341 Approach and retraction in the plane (SAR)
Group 47: External NC languages modally effective
Name Meaning
G290 * Siemens mode
G291 External mode
Transformations
Name Meaning
TRACYL Cylinder. Peripheral surface transformation
TRANSMIT Transmit: Polar transformation
TRAFOOF Deactivate transformation
