2-14 Screw Torque
Description Torque
LOCK SCREW PAN MECH M3*8.5-3.5 BLACK NYLOCK
SPRING WASHER
5.0±0.2 Kgf-cm
SCREW PAN TAP M3*8 NI 6.5±0.3 Kgf-cm
SCREW PAN TAP M3*6 NI 5.0±0.5kgf-cm
SCREW PAN HEAD TAP M2.6*6 5.0±0.2 Kgf-cm
SCREW CAP TAP M2.6*7 WASHER BLACK 5.0±0.5kgf-cm
SCREW PAN MECH M3*10 NI NYLOK 3.0±0.5kgf-cm
SCREW ISO M3*8MM NI PH W/LW 3.0±0.5kgf-cm
SCREW PAN HEAD TAP M2.6*8 5.0±0.2 Kgf-cm
SCREW HEX I/O #4-40 H4*L8 NI NYLOK 3.0±0.2 Kgf-cm
SCREW PAN MECH M2.6*6 Ni NYLOK 3.0±0.5 Kgf-cm
STEP SCREW FOR DMD M2.6*16.2mm X116 3.0±0.2 Kgf-cm
SCREW PAN MECH M2.6*5 Ni NYLOK 3.0±0.5 Kgf-cm
ADAPTER SCREW M2.6 X113 5.0±0.2Kgf-cm
SCREW PAN MECH M3*6 NI 3.0±0.5kgf-cm
HEX SPACER M3 H=17mm L=5mm AL PD726 1.5±0.5 Kgf-cm
SCREW BINDING MECH M2.6*6 Ni NYLOK 3.0±0.5kgf-cm
