optris Xi 80 User Manual

-16 -
2.2 Electrical specifications
Power Supply:
Xi 80/410: USB/ PoE/ 5-30 VDC
Xi 400: USB
Current draw:
Max 500 mA
AO: Output Standard/Internal Process
Interface (PIF out)
0 - 10 V (Xi 400), 0/4 – 20 mA (Xi 80/410) (Main measure area, measure area, internal temperature, flag status,
recording status, line scan status, alarm, frame sync, fail-safe, external communication)
[►Appendix F – Wiring diagrams PIF]
AI: Input Standard/Internal Process
Interface (PIF in)
0 - 10 V (Emissivity, ambient temperature, reference temperature, uncommitted value, flag control, triggered
recording, triggered snapshots, triggered line-scanner, triggered event grabber, reset peak-/valley-hold, switch
temperature range)
[►Appendix F – Wiring diagrams PIF]
DI: Digital Input Standard Process
Interface (Xi 400)
Flag control, triggered recording, triggered snapshots, triggered line-scanner, triggered event grabber, reset peak-
/valley-hold, switch temperature range
[►Appendix F – Wiring diagrams PIF]
Digital interface:
Xi 80/410: USB 2.0/ Ethernet/ RS485
Xi 400: USB 2.0/ optional USB to GigE (PoE) conversion
