optris Xi 80 User Manual

-58 -
4.1.5 Industrial Process Interface for Xi 80/410 (optional)
For use in industrial environment the industrial process interface with 500 V ACRMS isolation voltage between
Xi and process is available (connection box with IP65, 5 m, 10 m or 20 m standard or high temperature cable
for camera connection, terminal for process integration). [►Appendix F – Wiring diagrams PIF]
Pin assignment PIF cable (industrial process interface)
Figure 29: Connections of the industrial Process Interface for
Xi 80/410
GREEN
RS485 B
YELLOW
RS485 A
WHITE
12 V
BROWN
GND
SHIELD
GND
