optris Xi 80 User Manual

-38 -
3.2.3 Shutter
To protect the optics of the camera, an optional shutter (closing mechanism) can be purchased. It is
equipped with a servomotor that can open and close a mechanical lock as needed. The special feature of
the shutter is not only the opening and closing, but also the complete seal in the closed state. This ensures
that the shutter is completely closed and no dirt can get on the optics.
• The shutter has a 100 ms fast-closing mode.
• Complete seal when closed.
• Includes a control box for connections.
• Shutter can be used in combination with Process Interface (PIF).
• The corresponding mounting bracket (Part-No.: ACXIAPLAB) is mandatory.
• Material: Stainless steel
• Weight: 550 g / 826 g Shutter with mounting bracket
• When using more than one shutter and the opening / closing of the shutter should be
simultaneously, the switch S4 on one control box must be set to mA and the others to mV
(see Figure 16).
• Ambient temperature: 0...60 °C (T
Amb
camera: 0...50 °C); with water cooled housing up to
250 °C
