optris Xi 80 User Manual

-70 -
5 Functions
5.1 Ethernet Xi 80/410
The Xi 80/410 has a direct Ethernet interface. The advantage is cable lengths of up to 100 m. For example, a
switch can be used to extend the distances. The associated Ethernet cable (Order No.: ACXIETCBx) must
be ordered separately. Ethernet is supported from software version Rel. 3.2.3020.0 and firmware 3008.
Using the Ethernet connection, the device must be supplied with power. This can be done either via:
• the internal PIF cable via the terminal block (5-30 V)
• the stackable PIF (5-24 V, Order No.: ACXIPIFCBx)
• PoE (Power over Ethernet)
For the PoE variant, a PoE adapter (Order No.: ACXIETPOECB1) and a PoE injector (Order No.:
ACPIPOE) or PoE switch (e.g. Netgear GS510TLP) are also required.
