Table 8-1 Diagnostics: System Information
Field Description
Diagnostic Version The Diagnostics Utility version.
RAM Size (bytes) Shows the total RAM capacity.
Physical Address (ENET) Shows the network MAC address assigned to the
Ethernet port.
Physical Address (Wi-Fi) Shows the network MAC address assigned to the
wireless adapter.
IP Address Shows the DHCP IP address assigned to the workstation.
C Total Size (bytes) Shows the total capacity of the C drive.
C Free Size (bytes) Shows the available capacity of the C drive.
D Total Size (bytes) Shows the total capacity of the D drive.
D Free Size (bytes) Shows the available capacity of the D drive.
Microsoft Window Ver Shows the Microsoft Windows operating system version
number.
Driver Version Shows the PCWSAPI driver version number.
Workstation Model Shows the workstation model.
BIOS Version Shows the BIOS version number.
Hardware Revision Shows the System Board revision letter.
Motherboard SN Shows the motherboard serial number.
UED CTRL Version Shows the USB port driver version number. The
Workstation 6 uses this driver to enable or disable USB
ports.
E2PROM Driver Version Shows the E2PROM driver version number.
CAL Version Shows the Client Application Loader version number.
UUID Shows the Universally Unique Identifier, which enables
distributed systems to uniquely identify information
without significant central coordination.
Testing the LCD Display
On the LCD Display tab, you can test the following LCD display features:
• Brightness
• Backlight
• Colors
• Backlight Controls
1. To test brightness, press the Dim, Normal, and Bright buttons in the LCD
Intensity Control group.
2. To test the backlight, press Backlight Off to ensure the backlight turns on and off.
3. To test the colors, press the Red, Green, Blue, Black, and White buttons in the
Display Color group.
Chapter 8
Testing the LCD Display
8-2
