Workstation 6 Utilities and Configurations 23
Field Description
UED CTRL Version Shows the USB port driver version number. The
Workstation 6 uses this driver to enable or disable USB
ports.
E2PROM Driver Version Shows the E2PROM driver version number.
CAL Version Shows the Client Application Loader version number.
UUID Shows the Universally Unique Identifier, which enables
distributed systems to uniquely identify information
without significant central coordination.
Testing the LCD Display
On the LCD Display tab, you can test the following LCD display features:
• Brightness
Tap the Dim, Normal, and Bright buttons in the LCD Intensity Control group.
• Backlight
Tap Backlight Off to ensure the backlight turns on and off.
• Colors
Tap the Red, Green, Blue, Black, and White buttons in the Display Color group.
• Backlight Controls
You can set a timer to switch off the backlight after a period of inactivity.
1. Enter a time in seconds in the Backlight Reprime field.
2. Tap Reprime Backlight to set the timer. Set the value to 0 to disable the
timer and allow the backlight to stay on indefinitely.
3. Tap Backlight On to enable the timer.
4. You can disable the timer after testing by tapping Backlight Off.
Testing the Integrated Magnetic Stripe Reader
On the MSR tab, you can test that the integrated magnetic stripe reader functions
correctly and retrieves the expected results.
You can test the card reader in:
• Special Mode
This mode converts scanned data into a buffer and sends the information to an
application for processing.
Special Mode accepts inputs in 2 or 3 tracks.
• Magtek Mode
This mode emulates keyboard input with diagnostic and employee cards.
Magtek Mode accepts inputs in 1, 2, or 3 tracks.
You can tap Reset Mag Reader to reset mag reader settings, and you can tap Clear All
Data to clear the previously input card data.
Testing the Encrypted Magnetic Stripe Reader
On the Encrypted MSR tab, you can test the magnetic card reader with encryption
enabled.
