Tape Drive Description
24 T10000: Interface Reference Manual August 2016
FIGURE 1-3 T10000D Tape Drive Rear View
1. Tape transport interface (TTI) connector 4. Fibre Channel, LC interface ports (2) A & B
2. Recessed switch (service only) 5. RJ-45 Ethernet connector
3. Power supply connector
