Note: A check mark appears in the Update box adjacent to the
parameter.
Data Path Key Management Procedures
Operator Tasks 3-17
5. Click Commit at the bottom of the dialog box.
Note: The drive performs an initial program load (IPL).
See "Data Path Key Management" on page 1-9 for additional information.
Figure 3–5 Turn DPKM On
To Turn DPKM Off
1. Set the drive offline.
2. Select Drive Data from the Configure menu.
3. Select Encrypt from the Configure Drive Parameters dialog box.
4. Select the Yes option for the Turn encryption off parameter.
Note: A check mark appears in the Update box adjacent to the
parameter.
5. Click Commit at the bottom of the dialog box.
Note: The drive performs an initial program load (IPL).
