View or Change Configuration Settings
4-8 StorageTek T10000 Tape Drive Operator's Guide
1. Do one of the following actions:
a. Press Menu to bypass.
b. Press Select to start the change mode.
2. Press Select to increment character until desired value appears, then press Menu.
3. Repeat step 2 for each character.
4. Press Menu to advance to the next submenu; or, press Select to restart the change
mode.
Port A/B Custom/Normal WWN Submenu
This submenu appears only when the Custom WWN is in use or when one is being
created/edited.
WWN Custom appears whenever a Custom WWN is in use, or is being created/edited.
WWN Custom also appears when the drive is using dynamic WWN, set by a library
invoking dWWN.
Procedure:
■ Do one of the following actions:
– Press Menu to bypass to the next submenu.
– Press Select to toggle the selection to WWN Normal.
WWN Normal selection recalls the stored normal WWN from the drive EEPROM.
Procedure:
■ Do one of the following actions:
– Press Menu to recall the stored Normal WWN, and advance to the next
submenu.
– Press Select to toggle the selection to WWN Custom.
Port B Attributes Menu
The operator panel window shows either View PrtB ? ( online) or Cfg PrtB ?
(offline).
View or change Port B attributes as defined in the preceding port A/B attributes
submenus (see "Port A Attributes Menu" on page 4-4).
Procedure:
■ Press Menu to bypass or press Select to enter the port attributes submenus.
Emulation Mode Submenu (FCP)
Note: Manufacturing ships Fibre Channel (FCP) drives with the
Emul STD option selected. Use the special emulation modes ( Emul
9840 and Emul 9940 ) only at the direction of company technical
support.
Procedure:
■ Do one of the following actions:
