Replacing a ZS3-2 HDD or SSD
2.
If you are not physically at the system, turn on the locator indicator by clicking
the locator icon .
3.
At the front of the controller, pinch the air filter's left and right release levers
inward (1).
4.
Pivot the air filter forward and lift if out of the chassis (2).
5.
Press the release button of the failed drive, and pivot the release lever open to
the right.
Servicing the ZS3-2 Controller 131
