7420 Controller Hardware Overview
Slot Mfg Part Number Description Max Note
the SAS-2 internal
HBA
0 371-4325-02 8Gb 2-port FC HBA 6 Optional FC target or
initiator (Backup) for
the 7420 controller
0 7051223 2-port optical 10GbE
NIC
6 Optional
recommended front-
end for the 7420
controller
0 7054739 4-port copper NIC 6 Optional
recommended front-
end for the 7420
controller
1 F375-3609-03
(7059331 for EU
countries)
2-port SAS external
HBA
6 Base configuration
(2 minimum)
2 F375-3609-03
(7059331 for EU
countries)
2-port SAS external
HBA
6 Additional optional
back-end
2 7054739 4-port copper NIC 6 Optional
recommended front-
end
2 371-4325-02 8Gb DP FC HBA 6 Optional FC target or
initiator (Backup)
2 375-3606-03 CX1 InfiniBand
HCA
4 Optional
recommended front-
end
2 7051223 2-port optical 10GE
NIC
6 Optional
recommended front-
end
2 375-3696-01 CX2 InfiniBand
HCA
4 Optional
recommended front-
end
3 F375-3609-03
(7059331 for EU
countries)
2-port SAS external
HBA
6 Additional optional
back-end
3 7054739 4-port copper NIC 6 Optional
recommended front-
end
3 371-4325-02 8Gb 2-port FC HBA 6 Optional FC target or
initiator (Backup)
3 375-3606-03 CX1 InfiniBand
HCA
4 Optional
recommended front-
end
Servicing the 7x20 Controller 225
