7420 Controller Hardware Overview
Slot Mfg Part Number Description Max Note
3 7051223 2-port optical 10GE
NIC
6 Optional
recommended front-
end
3 375-3696-01 CX2 InfiniBand
HCA
4 Optional
recommended front-
end
4 7054739 4-port copper NIC 6 Optional
recommended front-
end
4 375-3606-03 CX1 InfiniBand
HCA
4 Optional
recommended front-
end
4 7051223 2-port optical 10GE
NIC
6 Optional
recommended front-
end
4 371-4325-02 8Gb 2-port FC HBA 6 Optional FC target or
initiator (Backup)
4 375-3696-01 CX2 InfiniBand
HCA
4 Optional
recommended front-
end
C 7056175 Cluster Controller
200
1 Cluster base
configuration
5 7054739 4-port copper NIC 6 Optional
recommended front-
end
5 375-3606-03 CX1 InfiniBand
HCA
4 Optional
recommended front-
end
5 7051223 2-port optical 10GE
NIC
6 Optional
recommended front-
end
5 371-4325-02 8Gb 2-port FC HBA 6 Optional FC target or
initiator (Backup)
5 375-3696-01 CX2 InfiniBand
HCA
4 Optional
recommended front-
end
6 F375-3609-03
(7059331 for EU
countries)
2-port SAS external
HBA
6 Additional optional
back-end
6 7054739 4-port copper NIC 6 Optional
recommended front-
end
6 371-4325-02 8Gb 2-port FC HBA 6 Optional FC target or
initiator (Backup)
226 Oracle ZFS Storage Appliance Customer Service Manual • July 2016
