7420 Controller Hardware Overview
Slot Mfg Part Number Description Max Note
6 375-3606-03 CX1 InfiniBand
HCA
4 Optional
recommended front-
end
6 7051223 2-port optical 10GE
NIC
6 Optional
recommended front-
end
6 375-3696-01 CX2 InfiniBand
HCA
4 Optional
recommended front-
end
7 F375-3609-03
(7059331 for EU
countries)
DP SAS external
HBA
6 Additional optional
back-end
7 7054739 4-port copper NIC 6 Optional
recommended front-
end
7 371-4325-02 8Gb 2-port FC HBA 6 Optional FC target or
initiator (Backup)
7 375-3606-03 CX1 InfiniBand
HCA
4 Optional
recommended front-
end
7 7051223 2-port optical 10GE
NIC
6 Optional
recommended front-
end
7 375-3696-01 CX2 InfiniBand
HCA
4 Optional
recommended front-
end
8 F375-3609-03
(7059331 for EU
countries)
2-port SAS external
HBA
6 Base configuration
(2 minimum)
9 371-4325-02 8Gb 2-port FC HBA 6 Optional FC target or
initiator (Backup)
9 7051223 2-port optical 10GbE
NIC
6 Optional
recommended front-
end
9 7054739 4-port copper NIC 6 Optional
recommended front-
end
7420 NIC/HBA Options - This table describes NIC/HBA PCIe card options for standalone and
cluster configurations.
TABLE 32
7420 Controller NIC/HBA Options
Mktg Part Number Description Mfg Part Number
SGX-SAS6-INT-Z 8-port 6Gb/s SAS-2 internal HBA 7054001
Servicing the 7x20 Controller 227
